Formula Electric Vehicle History


ePBR18





Dimensions

  • Length: N/A
  • Width: N/A
  • Height: N/A
  • Wheel Base: N/A
  • Front Track: N/A
  • Rear Track: N/A
  • Weight: 265kg

Accumulator

  • 88 Lithium Polymer cells in a 4 parallel, 72 series configuration with a 7.2KWh capacity at 300V
  • Orion AMS.

Braking

  • Tilton master cylinders with custom biasing system. Wilwood calipers. Custom, floating stainless steel brake rotors.

Controls

  • Acrylic steering wheel and dashboard. Smart phone driver display with custom application.

Frame and Body

  • Alloy steel space frame.
  • Fiberglass sandwhich body panels.

Tractive System

  • EMRAX 208 brushless synchronous 3-phase AC motor paired with a UNITEK controller.
  • Chain drive with 4 gear ratio to Quaife limited slip differential.

Suspension

  • Front pushrod and rear pullrod suspension with Kaz dampers. Jongbloed wheels with Hoosier tires.

ePBR16

electric team 2016 - nebraska470x314.jpg

Dimensions

  • Length: 3133 mm
  • Width: 1513 mm
  • Height: 1158 mm
  • Wheel Base: 1720 mm
  • Front Track: 1510 mm
  • Rear Track: 1495 mm
  • Weight: 272 kg

Accumulator

  • 60kW pack made up of 72 lithium polymer cells, maximum pack voltage of 300V.
  • Orion AMS.

Braking

  • Tilton master cylinders with custom biasing system. Wilwood calipers. Custom, floating stainless steel brake rotors.

Controls

  • Fiberglass steering wheel and aluminum dashboard. Smart phone driver display with custom application.

Frame and Body

  • Alloy steel space frame.
  • Fiberglass sandwhich body panels.



Tractive System

  • EMRAX 228 brushless synchronous 3-phase AC motor paired with a UNITEK controller.
  • Chain drive with 3.29 gear ratio to Quaife limited slip differential.

Suspension

  • Front pushrod and rear pullrod suspension with Kaz dampers. Jongbloed wheels with Hoosier tires.

ePBR15

Dimensions

  • Length: 3058 mm
  • Width: 1510 mm
  • Height: 1148 mm
  • Wheel Base: 1720 mm
  • Front Track: 1510 mm
  • Rear Track: 1495 mm

Accumulator

  • Single unit configuration. 72 lithium polymer cells with total pack voltage of 300V. Orion AMS.

Braking

  • Tilton master cylinders with custom biasing system. Wilwood calipers. Custom, floating stainless steel brake rotors.

Controls

  • Carbon fiber steering wheel and dashboard. Smart phone interface display with custom application.

Frame and Body

  • Alloy steel space frame.
  • Fiberglass sandwhich body panels.

Tractive System

  • EMRAX brushless synchronous 3-phase AC motor. Chain drive to mechanical limited slip differential.

Suspension

  • Front pushrod and rear pullrod suspension with Kaz dampers. Jongbloed wheels with Hoosier tires.

ePBR14

electric team 2014470x314 (1).jpg

Dimensions

  • Length: 2741 mm
  • Width: 1453 mm
  • Height: 1085 mm
  • Wheel Base: 1535 mm
  • Front Track: 1201 mm
  • Rear Track: 1202 mm
  • Weight: 213 kg

Accumulator

  • Side pod configuration. 72 lithium polymer cells with total pack voltage of 300V. Orion AMS.

Braking

  • Tilton master cylinders with custom biasing system. Wilwood calipers. Custom, floating stainless steel brake rotors.

Controls

  • Carbon fiber steering wheel with smart phone interface display and custom application.

Frame and Body

  • Alloy steel space frame.
  • Fiberglass sandwhich body panels.

Tractive System

  • EMRAX brushless synchronous 3-phase AC motor. Chain drive to mechanical limited slip differential.

Suspension

  • Front pushrod and rear pullrod suspension with Kaz dampers. Jongbloed wheels with Hoosier tires.

ePBR13


Accumulator

  • 72V single unit with twelve lithium ion cells.

Braking

  • Independent front and rear. Brembo calipers with custom steel rotors.



Controls

  • Steering wheel mounted smart phone interface with custom application.

Tractive System

  • Dual Agni motors. Chain drive to mechanical limited slip differential.

Body

  • Composite Carbon Reinforced Polymer Monocoque.

Suspension

  • Front and rear pushrod suspension with Kaz dampers and anti sway bars. Jongbloed wheels and Hoosier tires.

ePBR12 (Hybrid)

Accumulator

  • 72V single unit with twelve lithium ion cells.

Braking

  • Independent front and rear. Brembo calipers with custom steel rotors.

Controls

  • Steering wheel mounted interface and display.

Tractive System

  • Dual Agni motors. Chain drive to mechanical limited slip differential.

Body

  • Composite Carbon Reinforced Polymer Monocoque.

Suspension

  • Front and rear pushrod suspension with Kaz dampers and anti sway bars. Hoosier tires.

ePBR11 (Hybrid)
